Treemap Firmware Bloat Visualizer (Rust/WebASM)
by clbrmbr·Mar 5, 2026·1 point·0 comments
AI Analysis
●●●BangerWizardryEye CandyNiche Gem
WASM treemap visualizer beats Bloaty for instant firmware bloat diagnosis.
Strengths
- •Entirely Rust/WASM eliminates framework overhead—direct Canvas rendering is snappy
- •Clever hue-distribution algorithm ensures all colors used evenly across treemap
- •DWARF debug tracing infers ownership of unnamed .rodata sections, solving real embedded pain
Weaknesses
- •Limited to STM32/ESP32—macOS binary support missing, reducing cross-platform reach
- •Requires debug symbols (-g flag) or visualization is incomplete and unhelpful
Category
Target Audience
Embedded firmware developers (STM32, ESP32, ARM Cortex)
Similar To
Bloaty · Go's binary visualization tools
Post Description
tl;dr: i built a webpage that shows you where all the flash space in your firmware project has gone.
Direct link to the tool: https://bondhome.github.io/elfvis/
